Chapter 5 Parameters
_
VFD-E Series
5-22 Revision August 2006, 01EE, SW--PW V1.03/CTL V2.03
 Output Signal for Base Block
Applications Purpose Functions
Related
Parameters
General application
Provide a signal for
running status
When executing Base Block, a signal
is given for external system or control
wiring.
03.00~03.01
 Overheat Warning for Heat Sink
Applications Purpose Functions
Related
Parameters
General application For safety
When heat sink is overheated, it will
send a signal for external system or
control wiring.
03.00~03.01
 Multi-function Analog Output
Applications Purpose Functions
Related
Parameters
General application
Display running
status
The value of frequency, output
current/voltage can be read by
connecting a frequency meter or
voltage/current meter.
03.06
