1. SETTING UP YOUR WIRELESS VEHICLE CONTROL BOARD*:
BEFORE CONTINUING MAKE SURE YOUR GATE IS CLOSED. TURN THE GATE OFF BY TURNING THE
SWITCH TO THE OFF POSITION ON THE BOTTOM OF THE CONTROL BOX.
*The following steps can be performed indoors BEFORE digging and burying the Sensor Probe.
A. Remove the cover on Control Board by sliding the outer black cover upward to access the Control Board and battery holder.
Shown below in Step 1A.
B. Insert/Install two C batteries (not included) into the battery holder with correct polarity aligned.
Shown below in Step 1B.
2. TEACHING THE TRANSMITTER TO THE WIRELESS VEHICLE CONTROL UNIT BOARD:
BEFORE CONTINUING, MAKE SURE YOUR TRANSMITTER IS ALREADY CAPABLE OF OPENING THE GATE.
A. On Control Board, press and hold the button below the “LEARN” LED light until the RED “LEARN” LED light is on.
(Example 2A)
B. Release the button, the RED “LEARN” LED should remain ON indicating it is in “LEARNING” mode and waiting for the signal from
the transmitter.
NOTE
The Control Unit will automatically exit “LEARNING MODE” after 60 seconds if no valid signal from Remote Transmitter is detected.
PRESS and HOLD Learn button on Control
Board until RED LED light turns on and
remains solid on.
Step 1A
Step 1B
Step 2A &
Step 2B
Slide Cover Up
to Remove
"LEARN" LED
"LEARN" Button
To Next Page
