Menu Description Sub-Menu Description
Addr Set Address A001 - A512 Setting up a starting DMX address of the xture
ChMd User Mode 16Ch / 30Ch
16 channel mode
30 channel mode
SLMd Operation Mode
Mast / Sl 1 /
Sl 2 / D512
Mast - Master mode
SL1 - Slave Mode synchronized
SL2 - Slave Mode desynchronized
D512 - DMX Mode
SdMd Sound Mode
Sd 1 / Sd 2 /
Sd 3 / Sd 4
Sd1 - Sound Mode 1
Sd2 - Sound Mode 2
Sd3 - Sound Mode 3
Sd4 - Sound Mode 4
Auto Auto Mode Aut1 - Aut4
Aut1 - Auto Mode 1
Sp1 - Sp9
Speed chase
setting
Aut2 - Auto Mode 2
Aut3 - Auto Mode 3
Aut4 - Auto Mode 4
Sens Sound sensitivity 0 - 100 Sound Sensitivty setting
Led Display Backlight On / Off
On - backlight constantly on
Off - backlight off after 2 minutes
diSP Display Rotation dISP / dSIP
dISP - display UP
dSIP - display DOWN
Pan Pan reverse No / Yes
no - normal Pan movement
yES - reverse Pan movement
Tilt Tilt reverse No / Yes
no - normal Tilt movement
yES - reverse Tilt movement
Ver Firmware version Vxx Firmware version display
Rset Fixture reset
Addr - Setting of the DMX address:
Press MENU to select ADDR, press ENTER to start setting.
Use the UP or DOWN keys to set the desired Address. Then press ENTER to conrm.
ChMd - Selection of the channel mode:
Press MENU to select CHND. Press ENTER to start setting. Select the channel mode using the
UP OR DOWN keys: successively 16CH and 30CH. Press ENTER again to conrm the selection.
- 16CH: 16 Channel mode
- 30CH: 30 Channel mode
SLMd - Selection of operating mode
Press MENU to select SLMD. Then press ENTER to start setting. MAST, SL1, SL2 OR D512 will be dis-
played. Press UP OR DOWN to choose Master or slave, then press ENTER again to conrm your selection.
MAST: Choose the device as master, SL1 / SL2 : Choose the device as slave or D512: for DMX512 opera-
tion.
