Giant EXPEDITION BIKES-2001 - 1 Sizing

- Pag. 1. -
1. Sizing.
The actual frame measurements and geometries are listed below.
Size M - 49 cm. L - 54 cm. XL - 60 cm.
A. Top Tube [mm.] (measured horizontally) 570 590 605
B. Seat Tube [mm.] 495 540 600
C. Seat Tube Angle 72 degrees
D. Head Tube Angle 70 degrees
E. B.B. Drop [mm.] 22
F. Chain stays [mm.] 425
G. Fork Rake [mm.] 43
H. Trail [mm.] 78
I. Wheel Base [mm.] 1050 1070 1090
Rear Wheel Travel 3.2”
Figure 1.
