Giant NRS 2004 - Exploded view

- Pag. 4. -
3. Exploded view.
Please see figure 2.
NR. DESCRIPTION REMARKS Q’TY PER BIKE
1 Front triangle 1
2 Chain stays 1
3 Seat stays 1
4 Lower shock mount Set 1
4-1 Fixing bolt 1 pc. per set
4-2 Washer
2 pcs per set
(same as 6-5 and 8-2)
4-3 Nut 1 pc. per set
5 Fixing bolt upper shock mount 1
6 Pivot parts set Seat tube 1
6-1 Fixing nut 1 pc. per set
6-2 Bearing 2 pcs per set
6-3 Aluminium bushing, 10.5mm 2 pcs per set
6-4 Aluminium bushing, 28.3mm 1 pc. per set
6-5 Washer
1 pc. per set
(same as 4-2 and 8-2)
6-6 Fixing bolt 1 pc. per set (same as 8-1)
7 Pivot parts set Seat stays - linkage plates 2
7-1 Fixing bolt 1 pc. per set
7-2 Teflon™ bushing 1 pc. per set (note 1)
7-3 Bearing 1 pc. per set
7-4 Spacer 1 pc. per set
8 Pivot parts set Chain stays - bottom bracket 1
8-1 Fixing bolt 1 pc. per set (same as 6-6)
8-2 Washer
1 pc. per set
(same as 4-2 and 6-5)
8-3 Bearing 2 pcs per set
8-4 Spacer 2 pcs per set
8-5 Fixing nut 1 pc. per set
9 Pivot parts set Dropouts - chain stays 2
9-1 Fixing bolt 1 pc. per set
9-2 Teflon™ washer 2 pcs per set
9-3 Aluminium spacer 2 pcs per set
9-4 Bearing 1 pc. per set
10 Rear shock Incl. hardware 1
11 Linkage plates Set LH and RH 1
12 Bolt M4 (note 2) 2
13 Replaceable dropout Incl. bolt and nut 1
Note 1. Part # 7-2 (Teflon™ bushing) only on frames with composite linkage plates
(NRS™ Composite).
Note 2. Part # 12 (bolt M4) only on frames with aluminium linkage plates
(NRS™-1, 2 and 3 and frame set NRS™).
