To Change the AC’s Travel:
1. Using a 6mm Allen wrench, remove the upper shock mounting bolt.
2. Pivot the shock backward or forward to align the eyelet with one of the two holes. The forward
most position is 5.3” travel and the rear position is 6.3” travel.
3. Install the bolt and tighten to the proper torque of 100-120 Kgf/cm (86-95 in.-lbs.).
4. After any adjustment is made to travel, readjust sag/spring tension and damping. See previous
sag setting instructions on page 11 for details. Please refer to the Sag Recommendations chart
below to set up your Giant AC bicycle.
AC Sag Recommendations:
EYE-TO-EYE SAG COMPRESSED SHOCK LENGTH
7.5” (190mm) Freeriding (5.3”): .49” (12.5mm) 7.0” (177.5mm)
Downhill: (6.3”): .69” (17.5mm)
6.8” (172.5mm)
