Giant WARP BIKES-2001 - Sizing

1. SIZING.
The actual frame measurements and geometries are listed below.
The WARP bikes are designed for sports and recreational use. Rear travel 4”.
Size S - 16.5” M - 18.5” L - 20.5”
A
Top Tube
(measured horizontally) [mm.]
560 580 600
B Seat Tube [mm.] 420 470 520
C Seat Angle 73 degrees
D Head Angle 71 degrees
E B.B. Drop [mm.] 15
F Chain Stay [mm.] 430
G Fork Rake [mm.] 38
H Trail [mm.] 76
I Wheel Base [mm.] 1047 1069 1091
Rear Travel [mm.] 105
