ENGLISH
DensiMat
- 4 -
2. GENERAL DESCRIPTION AND TECHNICAL CHARACTERISTICS
The instrument consists of an electronic hydrostatic balance DENSIMAT, with a
sensitivity of fifth decimal points.
GENERAL SPECIFICATIONS
Warm-up time
≥ 15 minutes
Operating temperature
+15°C / +30°C
Data output
RS232 I/O
Operating voltage
220 V - 15% / + 10 % (110 V optional)
Power consumption
10 VA
Dimensions and weight
210x355x360 mm - 7,5 kg ~
HYDROSTATIC BALANCE SECTION
Relative density
Measuring range: 0.5 - 2.25
Readability
0.00005
Repeatability
+/- 0.00005
Auto-calibration
With internal mass
Response time
6 sec.
THERMOMETER SECTION
Measuring temperature
Range 8 ÷ 32 °C
Sensitivity
0.025 °C
Readability
0.1 °C
Repeatability
+/- 0.05 °C (range 10 ÷30 °C)
Thermometric probe
Pt 100 1/3 DIN
EQUIPMENT
Standard
2 floaters (plungers) calibrated
for weight (50 g) and volume (20 ml)
2 double wall 70 ml cylinders - Power supply
On request
Cylinder for measurements in continuous
Pan for metrological control
Certificated masses - Certificated floaters
FLOATERS INTERCHANGEABLE IN MASS AND VOLUME
Particular care must be paid in the construction and calibration of floaters.
They are all interchangeable in mass and in volume in order to facilitate utilization; for
example to determine the specific gravity of a must or a given wine and the relative
ASV, 2 separate floaters can be used without problem to avoid contamination
(preliminary check of the compensation factor; see chapter 4.3).
To obtain the above both the suspension
1
wire and the surface of the glass have been
subject of many studies in order to resolve the problems caused by surface tension,
from the volume of wire and from electrostatic charges.
1
Realized with an antimagnetic material, inoxidizable and a diameter lower or equal of 0,20 mm
