SC230
UK
SC230
UK
10
In the event of an operating fault or failure, cut the power upstream of the control unit and call Technical Service.
Periodically check functioning of the safety devices. Any repairs must be carried out by specialised personnel
using original and certified materials.
WARNINGS FOR THE USER
•Before proceeding with installation, fit a magnetothermal or differential switch with a maximum capacity of
10A upstream of the system. The switch must guarantee omnipolar separation of the contacts with an opening
distance of at least 3 mm.
•To prevent possible interference, differentiate the power cables and always keep them separate (minimum
cross-section 1.5 mm²) from the signal cables (minimum cross-section 0.5 mm²).
•Make the connections referring to the following tables and to the attached screen-print. Be extremely careful to
connect in series all the devices that are connected to the same N.C. (normally closed) input, and in parallel all
the devices that share the same N.O. (normally open) input. Incorrect installation or improper use of the product
may compromise system safety.
•Keep all the materials contained in the packaging away from children, since they pose a potential risk.
•The manufacturer declines all responsibility for improper functioning of the automated device if the original
components and accessories suitable for the specific application are not used.
•After installation, always carefully check proper functioning of the system and the devices used.
•This instruction manual addresses persons qualified for installation of “live equipment”. Therefore, good
technical knowledge and professional practice in compliance with the regulations in force are required.
•Maintenance must be carried out by qualified personnel.
•Before carrying out any cleaning or maintenance operation, disconnect the control unit from the mains.
•The control unit described here may only be used for the purpose for which it was designed: 230 VAC
motorization of a sliding gate with a Gi.Bi.Di. Motor.
•Use of the product for purposes different from the intended use has not been tested by the manufacturer,
therefore any work is carried out on full responsibility of the installer.
•Mark the automated device with visible warning plates.
•Warn the user that children or animals may not play or stand around near the gate.
•Appropriately protect the danger points (for example, using a sensitive frame).
INSTALLATION WARNINGS
THE ANTI-CRUSHING FUNCTION DOES NOT RELIEVE THE INSTALLER FROM THE OBLIGATION
TO INSTALL THE SAFETY DEVICES AS REQUIRED BY THE REGULATIONS IN FORCE.
ELECTRICAL CONNECTIONS: FASTONS
ELECTRICAL CONNECTIONS: TERMINAL BOARDS
PROTECTION FUSES
11
Position Signal Description
1 CN2 CN3 Ground connection
2 CN4 CN5 Motor capacitor connection
Terminal Position
Signal
Description
1
PHASE
230 VAC power supply
M1
2 NEUTR
230 VAC power supply
3
LAMP
Flashlight output 230 VAC 40W
4
LAMP
Flashlight output 230 VAC 40W
Slow flashing in opening, turned off in pause, fast
flashing in closing.
5
COM
Motor common
6
OPEN
Motor connection (opening)
M2
7
CLOSE
Motor connection (closing)
8
PED
PEDESTRIAN input (N.O.)
9
START
START input (N.O.)
10
PHOTOCELL input (N.C.). If not used, jumper with terminal 13
11
SAFETY
SAFETY DEVICE input (N.C.). If not used, jumper with terminal 13
12
STOP
STOP input (N.C.). If not used, jumper with terminal 13 or set dip switch 10 to ON
M3
13
COM
COMMON INPUTS/OUTPUTS
14
GND
External accessory power supply and in ductive sensor ground (blue cable)
15
24 VAC
24 VAC external accessory power supply (photocells, radio, etc.)
16
SEC
24 VAC external safety device power supply present only during the operating cycle
17
WARNING
LIGHT
WARNING LIGHT output 24 VAC 3W max
Slow flashing in opening, turned off fixed in pause, fast
flashing in closing.
18
12V
Inductive sensor positive power supply (brown cable)
M4
19
IMP
Inductive sensor input (black cable)
20
GND
ANTENNA GROUND input
M5
21 ANT
ANTENNA SIGNAL input
Position Value Type Description
F1 500 mA FAST Protects the ACCESSORY and SAFETY DEVICE power supply outputs
F2 FAST Protects the control unit at the 230 VAC power supply input
F3 500 mA FAST Protects the flashlight output
3,15A
