GiBiDi TAIMEN T6 User Manual

28 29
UKUK
TAIMEN
TAIMEN
WARNINGS:
This product has been tested by GI.BI.DI. for full compliance with the requirements of the directives in force. GI.BI.DI. S.r.l. reserves
the right to change the technical data without prior notice in relation to product development.
READ CAREFULLY THESE INSTRUCTIONS BEFORE PROCEEDING WITH INSTALLATION.
Thank you for choosing GI.BI.DI.
DISPOSAL: GI.BI.DI. advises recycling the plastic components and to dispose of them at special authorised
centres for electronic components thus protecting the environment from polluting substances.
INTRODUCTION
WARNINGS FOR THE INSTALLER
The gearmotors TAIMEN T6-T12 allow easily and quickly automating of sectional doors and overhead doors of up to
15 sq.m. .
The automated device with integrated control unit facilitates system certification in accordance with EN12453.
Ÿ
guarantee omnipolar separation of the contacts with an opening
distance of at least 3mm.
ŸAll the packaging materials must be kept out of reach of children since they are potencial sources of danger.
ŸThe manufacturer declines all responsibility for proper functioning of the automated device if failing to use original
GIBIDI components and accessories suitable for the intended application.
ŸWhen installation has been completed, always carefully check proper functioning of the system and the
devices used.
ŸThis instruction manual addresses persons qualified for installation of “ live equipment “, therefore
good technical knowledge is required exercised as profession in compliance with the regulations in force.
ŸMaintenance must be performed by qualified personnel.
ŸBefore carrying out any cleaning or maintenance operation, disconnect the control unit from the mains.
ŸThis product has been designed and constructed solely for the use indicates in this document. Any other use may
cause damage to the product and be a source of danger.
ŸVerify the intended end use and take the necessary safety precautions.
ŸUse of the products for purposes different from the intended use has not tested by the manufacturer and the
operations performed are therefore on full responsibility of the installer.
ŸMark the automated device with visible warning plates.
Ÿ Warn the user that children and animals must not play or stand near the gate.
Ÿ Adequately protect the danger points, for example using a sensitive frame .
ŸCheck proper installation of the earthing system: connect all the metal parts of doors, gates, ecc. and all the
system components equipped with earthing plate.
ŸExclusively use original spare parts for any maintenance or repair.
ŸDo not make any modification to the components of the automated device unless expressly authorised by GIBIDI.
Before proceeding with the installation, fit a magnetothermal and differential switch with a maximum capacity of
10A upstream of the system. The switch must
WARNINGS FOR THE USER
ŸIn the event of an operating fault or failure, cut the power upstream of the control unit and call the Technical Service.
ŸPeriodically check the functioning of the safety devices. Any repair must be carried out by specialised personnel
using original and certified materials.
ŸThe appliance is not to be used by children or people with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given supervision or instruction.
ŸDo not access to the control unit for adjustments and/or maintenance.
ŸNever operate the opener when any persons are under or near the path of the garage door. Children must be
supervised at all times when near the garage door and when the opener is in use.
ŸAlways disengage the opener with the garage door in the fully closed position.
ŸBefore attempting to disengage the opener from any position other than fully closed, ensure that there are no
children / persons and solid objects under or near the path of the garage door.
ŸNever attempt to open or close the garage door by pulling on the engage / disengage cord.
ŸFor safety reasons always ensure that the garage door is fully open and stationary before driving into or out of the
garage.
ŸMaintain the visual contact with the automated device during the complete operation period.
WARNING: IMPORTANT SAFETY INSTRUCTIONS.
It is important for the safety of persons to follow these instructions.
Keep this instruction manual.
