TRANSMITTERS MANAGEMENT
Learning procedure:
ŸWhen the operator has stopped, push and release the LEARN button.
ŸRL appears on the display, the flashing light and courtesy light start blinking slowly.
ŸPush within 6 seconds any button of the transmitter you want to store.
ŸThe flashing light and courtesy light will do 3 fast blinkings to confirm that the storage has been completed.
ŸPush within 6 seconds any button of another transmitter to be stoted or wait to go out from the procedure.
Alternative learning procedure:
ŸIt is necessary to have a transmitter already stored.
ŸWhen the operator has stopped, push for 10 seconds the button 1 and 2 of a transmitter already stored.
ŸRL appears on the display, the flashing light and courtesy light start blinking slowly.
ŸPush within 6 seconds any button of the transmitter you want to store.
ŸThe flashing light and courtesy light will do 3 fast blinkings to confirm that the storage has been completed.
ŸPush within 6 seconds any button of another trasmitter to be stored or wait to go out from the procedure.
Complete cancellation of storage transmitters procedure:
ŸWhen the operator has stopped, push for 8 seconds the LEARN button.
ŸRL appears on the display, the flashing light and courtesy light start blinking slowly.
ŸThe flashing light and courtesy light will do 3 fast blinkings to confirm that the cancellation has been completed.
ŸRelease the LEARN button.
Assigning specifical functions to transmitter buttons:
It is possible to assign different functions to the transmitter buttons by setting tr parameter.
TRAVEL LEARNING AND ANTI-CRUSHING THRESHOLDS
During travel learning procedure, the software stores operation times and automatically learns the amperometric
values for the correct operation of the anti-crushing system.
The anti-crushing parameters can be modified later by menu AF.
Travel learning procedure:
Ÿ
ŸLL will appear on the display, the flashing light and courtesy light will blink slowly.
ŸPush and release the button CONFIRM or any button of a transmitter stored or enable the input NO.
ŸThe operator will do the following learning automatic manoeuvres :
§Complete closing in slow down.
§Complete opening at high speed (menu 5P).
§Complete closing at high speed (menu 5P).
§Complete opening at high speed with slow down (menu 5P+5L).
§Complete closing at high speed with slow down (menu 5P+5L).
ŸDuring automatic learning manoeuvres :
§Any interaction (photocells, frame, input NO, CONFIRM button) causes the end of the learning procedure that
must be repeated from the beginning.
§Anti-crushing system is disabled.
ŸAfter the procedure, the flashing light and courtesy light will do 3 fast blinkings to confirm that the learning has
been completed, LL will not appear on the display any more, the flashing light and courtesy light will not blink
any more.
When the operator has stopped and blocked, push the button CONFIRM for 5 seconds.
OPERATION PARAMETERS MODIFICATION
Access to the menu:
Ÿ
Ÿ5b, the first parameter of the menu, will appear on the display.
ŸUse buttons + or - to display the available parameters.
ŸPush the button CONFIRM to modify the parameter chosen or LEARN to go out from the menu.
ŸIn case the parameter has been modified, slide the available options with buttons + or -.
ŸIf you want to save the modification done, push the button CONFIRM, the selection will blink fast and the
parameter just modified will appear again on the display.
ŸIf you do not want to save the modification done, push LEARN to return to previous menu and do not save the
modification.
When the motor has stopped, push the buttons + and - at the same time and release them.
Confirm
Learn
Confirm
Learn
Confirm
Learn
/ /
Learn
Confirm
Confirm
Learn
LI
Confirm
Learn
dt
Confirm
Learn
Fl
Confirm
Learn
TR
Confirm
Learn
af
Confirm
Learn
AC
FC
Confirm
Learn
rt
Confirm
Learn
Confirm
Learn
nO
Confirm
Learn
Confirm
Learn
Confirm
Learn
Confirm
Learn
/ / / / /
/
/ / / / /
5b
r5
5l
5p
Confirm
Learn
Pf
/
/
PARAMETER MODIFICATION MENU
