- 17 -
2-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN1/2
5) LED_C
6) D_LED
7) SATA3 0/1/2/3
8) M2A_CPU
9) F_PANEL
10) F_AUDIO
11) F_U32
12) F_USB
13) SPI_TPM
14) BAT
15) CLR_CMOS
2
7
4
15
1
5 9
3
10
14
11
6 413 12 8
