Page #7 background imageLoading...
Page #7 background image
- 7 -
USB CPU:
- 1 x USB Type-C
®
port on the back panel, with USB 3.2 Gen 1 support
- 1 x USB 3.2 Gen 1 port on the back panel
- 1 x USB 2.0/1.1 port on the back panel
Chipset:
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
- 5 x USB 2.0/1.1 ports (3 ports on the back panel, 2 ports available through
the internal USB header)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
2 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
1 x M.2 Socket 3 connector
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI
2.0 module only)
1 x Clear CMOS jumper
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x USB Type-C
®
port, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 1 port
4 x USB 2.0/1.1 ports
1 x HDMI port
1 x DisplayPort
1 x D-Sub port
1 x RJ-45 port
3 x audio jacks
I/O Controller iTE
®
I/O Controller Chip

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Gigabyte A620M DS3H and is the answer not in the manual?

Gigabyte A620M DS3H Specifications

General IconGeneral
Processor manufacturerAMD
Compatible processor seriesAMD Ryzen 5, AMD Ryzen 7 7th Gen, AMD Ryzen 9 7th Gen
Supported processor socketsSocket AM5
Maximum internal memory supported by processor192 GB
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR5-SDRAM
Supported memory clock speeds4800, 5200, 5600, 6000, 6200, 6400, 6800, 7000, 7200, 7600 MHz
Supported memory clock speed (max)7600 MHz
Supported memory module capacities1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB, 48GB
Wi-FiNo
Ethernet interface typeGigabit Ethernet
USB 2.0 connectors1
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
Headphone outputs3
USB connector typeUSB Type-A, USB Type-C
DisplayPort version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
RAID levels0, 1, 10
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, SATA III
Cables includedSATA
Bundled softwareNorton® Internet Security (OEM version) LAN bandwidth management software
BIOS typeUEFI AMI
ACPI version5.0
BIOS memory size256 Mbit
Desktop Management Interface (DMI) version2.7
DirectX version12.0
Maximum resolution4096 x 2160 pixels
Parallel processing technology supportNot supported
Component forPC
Product colorBrown
Motherboard chipsetAMD A620
PC health monitoringFAN, Temperature, Voltage, Water cooling
Audio output channels7.1 channels
Motherboard form factormicro ATX
Windows operating systems supportedWindows 10 x64, Windows 11 x64
Package width265 mm
Package height54 mm
Package weight1067 g
Country of originChina
Quantity per shipping (inner) case1 pc(s)
Warranty period3 year(s)
Battery typeCR2032
Battery weight3 g
Battery technologyLithium-Manganese Dioxide (LiMnO2)
Weight and Dimensions IconWeight and Dimensions
Width244 mm
Height35 mm
