Gigabyte AC A520M DS3H User Manual

Storage Interface  CPU:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe
3.0 x4/x2 SSD support)
 Chipset:
- 4 x SATA 6Gb/s connectors
- Support for RAID 0, RAID 1, and RAID 10
USB  CPU:
- 4 x USB 3.2 Gen 1 ports on the back panel
 Chipset:
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
- 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 2 x system fan headers
 1 x addressable LED strip header
 1 x RGB LED strip header
 1 x M.2 Socket 3 connector
 4 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x USB 3.2 Gen 1 header
 1 x USB 2.0/1.1 header
 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only)
 1 x serial port header
 1 x Clear CMOS jumper
 1 x Q-Flash Plus button
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1 x DVI-D port
 1 x DisplayPort
 1 x HDMI port
 2 x SMA antenna connectors (1T1R)
(Note)
 4 x USB 3.2 Gen 1 ports
 2 x USB 2.0/1.1 ports
 1 x RJ-45 port
 3 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
- 7 -
(Note) Only for A520M DS3H AC.

Gigabyte AC A520M DS3H Specifications

General

Chipset	AMD A520
CPU Socket	AM4
Form Factor	Micro ATX
Memory Type	DDR4
Memory Slots	4
Max Memory	128 GB
PCIe x16 Slots	1
PCIe x1 Slots	2
SATA Ports	4
M.2 Slots	1
Audio	Realtek ALC887
Video Outputs	HDMI, DVI-D
LAN	Realtek GbE LAN
RAID Support	RAID 0, 1, 10
USB Ports	4x USB 2.0
