Gigabyte AC A520M DS3H User Manual

2-2 ProductSpecications
CPU  AM4 Socket:
- AMD Ryzen
™
5000 Series Processors
- AMD Ryzen
™
5000 G-Series Processors
- AMD Ryzen
™
4000 G-Series Processors
- AMD Ryzen
™
3000 Series Processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset  AMD A520
Memory  4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory
 Support for DDR4 3200/2933/2667/2400/2133 MT/s memory modules
 Dual channel memory architecture
 Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
 Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
 Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
 Integrated Graphics Processor:
- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
- 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz
* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
 Support for up to 3 displays at the same time
 Maximum shared memory of 16 GB
Audio  Realtek
®
Audio CODEC
 High Denition Audio
 2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To
congure 7.1-channel audio, access the audio software for audio settings.
LAN  Realtek
®
GbE LAN chip (1 Gbps/100 Mbps)
Wireless
Communication
Module
(Note)
 Intel
®
Wi-Fi AC 3168 (For PCB rev. 1.0, 1.2, 1.3)
 Intel
®
Wi-Fi AC 9260 (For PCB rev. 1.1)
- WIFI 802.11a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 4.2
- Support for 11ac wireless standard and up to 433 Mbps data rate
 AzureWave Wi-Fi AW-CB304NF (Realtek
®
RTL8821CE) (For PCB rev. 1.4)
- WIFI 802.11a, b, g, n, ac, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 4.2
- Support for 11ac wireless standard and up to 433 Gbps data rate
(Actual data rate may vary depending on environment and equipment.)
Expansion Slots  CPU:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
 Chipset:
- 2 x PCI Express x1 slots, supporting PCIe 3.0 (PCIEX1_1, PCIEX1_2)
- 6 -
(Note) Only for A520M DS3H AC.

Gigabyte AC A520M DS3H Specifications

General

Chipset	AMD A520
CPU Socket	AM4
Form Factor	Micro ATX
Memory Type	DDR4
Memory Slots	4
Max Memory	128 GB
PCIe x16 Slots	1
PCIe x1 Slots	2
SATA Ports	4
M.2 Slots	1
Audio	Realtek ALC887
Video Outputs	HDMI, DVI-D
LAN	Realtek GbE LAN
RAID Support	RAID 0, 1, 10
USB Ports	4x USB 2.0
