& Please visit GIGABYTE's website for details on conguring the audio software.
https://www.gigabyte.com/WebPage/697/realtek897-audio.html
You can change the functionality of an audio jack using the audio software. To congure
7.1-channel audio, access the audio software for audio settings.
Audio Jack Congurations:
Jack
Headphone/
2-channel
4-channel 5.1-channel 7.1-channel
Line In/Rear Speaker Out
a a a
Line Out/Front Speaker Out
a a a a
Mic In/Center/Subwoofer Speaker Out
a a
Front Panel Line Out/Side Speaker Out
a

Gigabyte B450M Specifications

General

Form Factor	Micro ATX
Chipset	AMD B450
Socket	AM4
Maximum Memory	64GB
Memory Slots	4
Storage Interface	1 x M.2, 4 x SATA 6Gb/s
LAN	Realtek GbE LAN
Video Outputs	1 x DVI-D, 1 x HDMI
Memory Speed	DDR4 3200(O.C.)/2933/2667/2400/2133 MHz
USB Ports	6 x USB 2.0
