2-2 ProductSpecications
CPU  AMD Socket AM4, support for:
AMD Ryzen
™
5000 Series Processors/
AMD Ryzen
™
5000 G-Series Processors/
AMD Ryzen
™
4000 G-Series Processors/
3rd Generation AMD Ryzen
™
processors/
2nd Generation AMD Ryzen
™
processors/
1st Generation AMD Ryzen
™
processors/
2nd Generation Ryzen
™
with Radeon
™
Vega Graphics processors/
1st Generation Ryzen
™
with Radeon
™
Vega Graphics processors/
Athlon
™
with Radeon
™
Vega Graphics Processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset  AMD B450
Memory  2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity)
of system memory
 Dual channel memory architecture
 Support for DDR4 2667
(Note 1)
/2400/2133 MHz memory modules
 Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
 Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
 Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
 Integrated Graphics Processor:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.0 version, HDCP 2.2, and HDR.
 Maximum shared memory of 16 GB
Audio  Realtek
®
Audio CODEC
 High Denition Audio
 2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To
congure 7.1-channel audio, access the audio software for audio settings.
LAN  Realtek
®
GbE LAN chip (1 Gbps/100 Mbps)
Expansion Slots  CPU:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
(Note 1)
 Chipset:
- 1 x PCI Express x1 slot, supporting PCIe 2.0 and running at x1
Storage Interface  CPU:
- 1 x M.2 connector (Socket 3, M key, type 22110/2280/2260/2242 SATA and
PCIe 3.0 x4/x2
(Note 2)
SSD support)
* Refer to "2-7 Internal Connectors," for the installation notices for the M.2 connector.
- 4 x SATA 6Gb/s connectors
 RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
 RAID 0, RAID 1, and RAID 10 support for SATA storage devices
(Note 1) Actual support may vary by CPU.
(Note 2) Supports only M.2 SATA SSDs when using an Athlon
™
with Radeon
™
Vega Graphics Processors.

Gigabyte B450M Specifications

General

Form Factor	Micro ATX
Chipset	AMD B450
Socket	AM4
Maximum Memory	64GB
Memory Slots	4
Storage Interface	1 x M.2, 4 x SATA 6Gb/s
LAN	Realtek GbE LAN
Video Outputs	1 x DVI-D, 1 x HDMI
Memory Speed	DDR4 3200(O.C.)/2933/2667/2400/2133 MHz
USB Ports	6 x USB 2.0
