Gigabyte B450M User Manual

- 8 -
USB  CPU:
- 4 x USB 3.2 Gen 1 ports on the back panel
 Chipset:
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 1 x system fan header
 1 x M.2 Socket 3 connector
 4 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x USB 3.2 Gen 1 header
 2 x USB 2.0/1.1 headers
 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only)
 1 x speaker header
 1 x Clear CMOS jumper
 1 x chassis intrusion header
Back Panel
Connectors
 1 x PS/2 keyboard port
 1 x PS/2 mouse port
 1 x HDMI 2.0 port
 4 x USB 3.2 Gen 1 ports
 2 x USB 2.0/1.1 ports
 1 x RJ-45 port
 3 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
BIOS  1 x 128 Mbit ash
 Use of licensed AMI UEFI BIOS
 PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Gigabyte B450M Specifications

General

Form Factor	Micro ATX
Chipset	AMD B450
Socket	AM4
Maximum Memory	64GB
Memory Slots	4
Storage Interface	1 x M.2, 4 x SATA 6Gb/s
LAN	Realtek GbE LAN
Video Outputs	1 x DVI-D, 1 x HDMI
Memory Speed	DDR4 3200(O.C.)/2933/2667/2400/2133 MHz
USB Ports	6 x USB 2.0
