Gigabyte B650 EAGLE - Page 9

- 9 -
Wireless
Communication
Module m
 Realtek
®
Wi-Fi 6 RTL8851BE
- WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands
- BLUETOOTH 5.3
- Support for 11ax 80MHz wireless
(Actual data rate may vary depending on environment and equipment.)
Expansion Slots  1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
 AMD Ryzen
™
7000 Series Processors support PCIe 4.0 x16 mode
 AMD Ryzen
™
8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
 AMD Ryzen
™
8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one
graphics card is to be installed, be sure to install it in the PCIEX16 slot.
 2 x PCI Express x16 slots (PCIEX1_1/PCIEX1_2), integrated in the CPU,
supporting PCIe 3.0 and running at x1
* The PCIEX1_1 and PCIEX1_2 slots become unavailable when an AMD Ryzen
™
8000
Series-Phoenix 2 processor is used.
 1 x PCI Express x16 slot (PCIEX1_3), integrated in the Chipset, supporting
PCIe 3.0 and running at x1
Storage Interface  1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,
M key, type 25110/22110/2580/2280 SSDs:
 AMD Ryzen
™
7000 Series Processors support PCIe 5.0 x4/x2 SSDs
 AMD Ryzen
™
8000 Series -Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
 AMD Ryzen
™
8000 Series -Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
 1 x M.2 connector (M2P_CPU), integrated in the CPU, supporting Socket 3,
M key, type 22110/2280 SSDs:
 AMD Ryzen
™
7000 Series Processors support PCIe 4.0 x2 SSDs
 AMD Ryzen
™
8000 Series -Phoenix 1 Processors support PCIe 4.0 x2 SSDs
 AMD Ryzen
™
8000 Series -Phoenix 2 Processors support PCIe 4.0 x2 SSDs
 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3,
M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support)
 4 x SATA 6Gb/s connectors
 RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
 RAID 0, RAID 1, and RAID 10 support for SATA storage devices
USB  CPU:
- 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 1 x USB Type-C
®
port on the back panel, with USB 3.2 Gen 1 support
 CPU+USB 2.0 Hub:
- 4 x USB 2.0/1.1 ports on the back panel
 Chipset:
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
- 1 x USB Type-C
®
port with USB 3.2 Gen 1 support, available through the
internal USB header
- 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
 Chipset+USB 2.0 Hub:
- 4 x USB 2.0/1.1 ports available through the internal USB headers
m Only for B650 UD AX.
