Gigabyte B660I AORUS PRO DDR4 - System Block Diagram

- 5 -
1-2 Motherboard Block Diagram
LGA1700 CPU
CPU CLK+/- (80~800 MHz)
DMI 4.0
LAN
4 SATA 6Gb/s
eSPI
Bus
SPI
Bus
DDI
DDI
Center/Subwoofer
Speaker Out
Line Out
MIC
S/PDIF Out
Rear Speaker Out
CODEC
iTE
®
Super I/O
4 USB 3.2 Gen 1
Intel
®
B660
DisplayPort
HDMI 2.0
USB 3.2
Gen 1 Hub
4 USB 2.0/1.1
BIOS
PCI Express 4.0 Bus
PCI Express 4.0 Bus
1 M.2 Socket 3
Intel
®
2.5GbE LAN
1 USB Type-C
®
,
with USB 3.2 Gen 2 support
1 USB Type-C
®
,
with USB 3.2 Gen 1 support
1 USB 3.2 Gen 2 Type-A
2 USB 3.2 Gen 1
DDR4 3200/3000/2933/
2666/2400/2133 MHz
x16
1 PCI Express x16
M.2 WIFI
RJ45
