Gigabyte G27F 2 User Manual

- 20 -
Gaming Monitor User Guide
• Move the Control button down ( ) to enter the Picture Mode
menu.
Move the Control button
up/down (
) to select the
desired option and press the
Control button to conrm.
• Move the Control button left (
) to enter the Volume menu.
Move the Control button
up/down (
) to adjust
the headphone volume
level and press the Control
button to conrm.
• Move the Control button right (
) to enter the the Input menu.
Refer to the “Selecting the Input Source” section.
Note: To close the menu, move the Control button left ( ).
Select Exit
Picture Mode
Standard
FPS
RTS/RPG
Movie
Reader
sRGB
Adjust Exit
Volume
50

Gigabyte G27F 2 Specifications

General

DDC/CI	Yes
Color gamut	95 %
Pixel pitch	0.3108 x 0.3108 mm
Screen shape	Flat
Backlight type	Edge LED
Display diagonal	27 \
Display technology	LED
Native aspect ratio	-
Maximum refresh rate	170 Hz
sRGB coverage (typical)	130 %
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Display brightness (typical)	400 cd/m²
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Number of upstream ports	1
Input current	3.42 A
AC input voltage	100 - 240 V
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
AC adapter output voltage	19 V
Power consumption (standby)	0.5 W
Power consumption (typical)	21 W
Cables included	AC, HDMI, USB
Tilt angle range	-5 - 20 °
Height adjustment	130 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Product color	Black
Market positioning	Gaming
Package type	Box

Weight and Dimensions

Depth (with stand)	193.63 mm
Width (with stand)	615.11 mm
Height (with stand)	535.66 mm
Weight (with stand)	5200 g
Depth (without stand)	42.21 mm
Height (without stand)	367.35 mm
Weight (without stand)	3500 g
