Quick Installation Guide
2
I. Quick Installation Guide :
The system bus speed can be set for 66,100,133MHz. The user can select the
system bus speed
(SW2)
and change the DIP SWITCH
(SW1)
selection to set
up the CPU speed for 500MHz – 1GHz and faster processor.
0
00
0
The CPU speed must match with the frequency RATIO. It will cause
system hanging up if the frequency RATIO is higher than CPU's.
SW1:
(O:ON / X:OFF)
DIP SWITCH
FREQ. RATIO
1 2 3 4
X 3 O X O O
X 3.5 X X O O
X 4 O O X O
X 4.5 X O X O
X 5 O X X O
X 5.5 X X X O
X 6 O O O X
X 6.5 X O O X
X 7 O X O X
X 7.5 X X O X
X 8 O O X X
X 8.5 O X O O
X 9 X X O O
X 9.5 X O O O
X 10 X O X X
X 10.5 O O X O
X11 O X X X
X11.5 X O X O
X12 O X X O
X13 X X X O
X14 O O O X
X15 X O O X
X16 O X O X
