Hardware Installation
3-3

J3: PWR FAN
Pin No. Function
1 GND.
2 +12V.
3 Sense.

J15: System FAN
Pin No. Function
1 GND.
2 +12V.
3 Sense.

JP1: PS/2 Keyboard Power On Selection
Pin No. Function
1-2 short Enable PS/2 Keyboard power on.
2-3 short Disable PS/2 Keyboard power on.(Default)

JP7: WAKE ON LAN ( Wake on LAN Connector)
Pin No. Function
1 +5VSB.
2 GND.
3 Signal.

J16: RING PWR ON ( Internal Modem Ring On)
Pin No. Function
1 Signal.
2 GND.

IR: INFRARED Connector (Optional)
Pin No. Function
1 IR DATA OUTPUT.
2 GND.
3 IR DATA INPUT.
4 NC.
5
VCC (
＋
5V).

JP9: Clear CMOS Function
Pin No. Function
1-2 Short Clear CMOS .
2-3 Short Normal.(Default)
