Hardware Installation - 20 -
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
First make sure your devices are compliant with the connectors you wish to connect. •
Before installing the devices, be sure to turn off the devices and your computer. Unplug the power •
cord from the power outlet to prevent damage to the devices.
After installing the device and before turning on the computer, make sure the device cable has •
been securely attached to the connector on the motherboard.
1
3
10
4
9
7
6
2
5
8
4
11
12
13
1) ATX_12V 8) BAT
2) ATX 9) F_ PANEL
3) CPU_FAN 10) F_ AUDIO
4) SYS_FAN1/SYS_FAN2 11) SPDIF_O
5) PWR_FAN 12) F_USB1/F_USB2
6) IDE 13) CLR_CMOS
7) SATA2 0/1/2/3/4/5
