GA-78LMT-S2 Motherboard Layout
Box Contents
GA-78LMT-S2 motherboard
Motherboard driver disk Two SATA cables
User's Manual I/O Shield
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
KB_MS
CPU_FAN
AM3+
ATX
F_AUDIO
AUDIO
M_BIOS
DDR3_1
DDR3_2
BAT
F_PANEL
ATX_12V
AMD 760G
SATA2
R_USB
CODEC
CLR_CMOS
VGA
USB_LAN
PCIEX16
PCIEX1
COM
F_USB2
GbE LAN
SYS_FAN
0 1
PCI
GA-78LMT-S2
3
2
SATA2
iTE
Super I/O
F_USB1
5
4
SATA2
AMD SB710
