Gigabyte GA-E350N - GA-E350 N Motherboard Layout

- 5 -
GA-E350N Motherboard Layout
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-E350N motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS
CPU_FAN
AMD E-350D APU
AMD A45 FCH
ATX
GA-E350N
F_AUDIO
AUDIO
B_BIOS
DDR3_0
DDR3_1
BAT
F_PANEL
ATX_12V
CODEC
CLR_CMOS
M_BIOS
VGA
USB_LAN
PCI
SPDIF_O
F_USB1
CI
F_USB2
PWR_LED
COM
Realtek
GbE LAN
0 1 2 3
SATA2
USB_HDMI
iTE Super I/O
SYS_FAN
LPT
