Gigabyte GA-F2A68HM-S1 User Manual

- 8 -
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 4 x SATA 3Gb/s connectors
 1 x APU fan header
 1 x system fan header
 1 x front panel header
 1 x front panel audio header
 1 x S/PDIF Out header
 2 x USB 2.0/1.1 headers
 1 x serial port header
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1 x D-Sub port
 1 x DVI-D port
 4 x USB 2.0/1.1 ports
 1 x RJ-45 port
 3 x audio jacks (Line In, Line Out, Mic In)
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 System voltage detection
 APU/System temperature detection
 APU/System fan speed detection
 APU overheating warning
 APU/System fan fail warning
 APU/System fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
BIOS  2 x 64 Mbit ash
 Use of licensed AMI UEFI BIOS
 Support for DualBIOS
™
 PnP 1.0a, DMI 2.7, SM BIOS 2.7, ACPI 2.0
Unique Features  Support for @BIOS
 Support for Q-Flash
 Support for Xpress Install
 Support for EasyTune
* Available functions in EasyTune may differ by motherboard model.
 Support for Smart Recovery2
 Support for ON/OFF Charge
Bundled
Software
 Norton
®
Internet Security (OEM version)
Operating
System
 Support for Windows 8.1/8/7 32-bit/64-bit
 Support for Windows XP 32-bit
* To support Windows XP 32-bit, you must install an AMD FM2 Trinity APU.

Gigabyte GA-F2A68HM-S1 Specifications

General

Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1333, 1600, 1866, 2133, 2400 MHz
Processor socket	Socket FM2+
Processor manufacturer	AMD
Compatible processor series	AMD A
Maximum number of SMP processors	1
S/PDIF out connector	Yes
Number of SATA III connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A68H
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows XP Home, Windows XP Professional
Maximum graphics card memory	2048 MB
Parallel processing technology support	-
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	64 Mbit
Bundled software	Norton Internet Security (OEM)

Weight and Dimensions

Depth	174 mm
Width	225 mm
