GA-H110M-A Motherboard Layout
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-H110M-A motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS
CPU_FAN
SYS_FAN
LGA1151
ATX
GA-H110M-A
F_AUDIO
SPDIF_O
AUDIO
DDR4_1 DDR4_2
BAT
ATX_12V
Intel
®
H110
F_USB30
R_USB30
R_USB
CODEC
CLR_CMOS
M_BIOS
HDMI
USB_LAN
PCIEX16
PCIEX1_1
PCIEX1_2
iTE
®
Super I/O
Realtek
®
GbE LAN
F_USBTPM
F_PANEL
SATA3
1 3 0 2
