Gigabyte GA-H61M-S2P-R3 User Manual

- 4 -
GA-H61M-S2P-R3/GA-H61M-S2P Motherboard Layout
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-H61M-S2P-R3/GA-H61M-S2P motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS
CPU_FAN
LGA1155
ATX
GA-H61M-S2P-R3/
GA-H61M-S2P
F_AUDIO
AUDIO
B_BIOS
DDR3_1 DDR3_2
BAT
F_PANEL
ATX_12V
Intel
®
H61
SATA2
R_USB30
CODEC
CLR_CMOS
M_BIOS
VGA
COM
LPT
USB_LAN
PCIEX16
PCI1
PCI2
PCIEX1
F_USB1
F_USB2
PCIe to PCI
Bridge
Realtek
®
GbE LAN
SYS_FAN
0
1
2
3
iTE
®
Super I/O
F_USB30
VIA
®
VL805

Gigabyte GA-H61M-S2P-R3 Specifications

General

Brand	Gigabyte
Model	GA-H61M-S2P-R3
Category	Motherboard
Language	English
