Gigabyte GA-H61M-S2P-R3 User Manual

- 7 -
1-2 ProductSpecications
CPU  Support for Intel
®
Core
™
i7 processors/Intel
®
Core
™
i5 processors/
Intel
®
Core
™
i3 processors/Intel
®
Pentium
®
processors/Intel
®
Celeron
®
processors
in the LGA1155 package
(Go to GIGABYTE's website for the latest CPU support list.)
 L3 cache varies with CPU
Chipset  Intel
®
H61 Express Chipset
Memory  2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than the size of
the physical memory installed.
 Dual channel memory architecture
 Support for DDR3 1333/1066/800 MHz memory modules
 Support for non-ECC memory modules
 Support for Extreme Memory Prole (XMP) memory modules
* To support XMP memory, you must install an Intel
®
22nm (Ivy Bridge) CPU.
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
 Integrated Graphics Processor:
- 1 x D-Sub port
Audio  Realtek
®
ALC887 codec
 High Denition Audio
 2/4/5.1/7.1-channel
* To congure 7.1-channel audio, you have to use an HD front panel audio module
and enable the multi-channel audio feature through the audio driver.
LAN  Realtek
®
GbE LAN chip (10/100/1000 Mbit)
Expansion Slots  1 x PCI Express x16 slot, running at x16
(The PCI Express x16 slot conforms to PCI Express 3.0 standard.)
* Whether PCI Express 3.0 is supported depends on CPU and graphics card compat-
ibility.
 1 x PCI Express x1 slot
(The PCI Express x1 slot conforms to PCI Express 2.0 standard.)
 2 x PCI slots
Storage Interface  Chipset:
- 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
USB  Chipset:
- Up to 6 USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
 VIA
®
VL805 chip:
- Up to 4 USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 4-pin ATX 12V power connector
 4 x SATA 3Gb/s connectors
 1 x CPU fan header
 1 x system fan header

Gigabyte GA-H61M-S2P-R3 Specifications

General

Brand	Gigabyte
Model	GA-H61M-S2P-R3
Category	Motherboard
Language	English
