Gigabyte GA-M61PME-S2 User Manual

Hardware Installation- 11 -
Back Panel  1 x PS/2 keyboard port
Connectors  1 x PS/2 mouse port
 1 x parallel port
 1 x serial port
 1 x D-Sub port
 4 x USB 2.0/1.1 ports
 1 x RJ-45 port
 3 x audio jacks (Line In/Line Out/Microphone)
I/O Controller  iTE IT8716 chip
Hardware Monitor  System voltage detection
 CPU/System temperature detection
 CPU/System fan speed detection
 CPU/System overheating warning
 CPU/System fan fail warning
 CPU fan speed control
(Note 2)
BIOS  1 x 4 Mbit flash
 Use of licensed AWARD BIOS
 PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features  Support for @BIOS
 Support for Download Center
 Support for Q-Flash
 Support for EasyTune
(Note 3)
 Support for Xpress Install
 Support for Xpress Recovery2
 Support for Virtual Dual BIOS
Bundled Software  Norton Internet Security (OEM version)
Operating System  Support for Microsoft
®
Windows
®
Vista/XP
Form Factor  Micro ATX form factor; 24.4cm x 22.5cm
(Note 1) Due to Windows Vista/XP 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
(Note 2) Whether the CPU fan speed control function is supported will depend on the CPU you install.
(Note 3) Available functions in Easytune may differ by motherboard model.

Gigabyte GA-M61PME-S2 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Processor system buses supported	2000 MHz
S/PDIF out connector	Yes
Number of Parallel ATA connectors	1
Controller interface type	SATA
Controller 2nd interface type	IDE
Headphone outputs	3
USB 2.0 ports quantity	4
BIOS type	AWARD
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Bundled software	Norton Internet Security
Networking features	Gigabit Ethernet
RAID levels	0, 1

Weight and Dimensions

Depth	225 mm
Width	244 mm
