Gigabyte GA-M61PME-S2 User Manual

GA-M61PME-S2 Motherboard - 10 -
1-2 Product Specifications
CPU  Support for Socket AM2 processors:
AMD Athlon
TM
64 FX processor/AMD Athlon
TM
64 X2 Dual-Core processor/
AMD Athlon
TM
64 processor/AMD Sempron
TM
processor
(Go to GIGABYTE's website for the latest CPU support list.)
Front Side Bus  2000 MHz FSB
Chipset  NVIDIA
®
GeForce 6100/nForce 430 chipset
Memory  2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory
(Note 1)
 Dual channel memory architecture
 Support for DDR2 800/667/533 MHz memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio  Realtek AL662 codec
 High Definition Audio
 2/4/5.1-channel
 Support for S/PDIF Out
 Support for CD In
LAN  RTL 8201CL chip (10/100 Mbit)
Expansion Slots  1 x PCI Express x16 slot
 1 x PCI Express x1 slot
 2 x PCI slots
Storage Interface  NVIDIA
®
GeForce 6100/nForce 430 chipset:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 2 x SATA 3Gb/s connectors supporting up to 2 SATA 3Gb/s devices
- Support for SATA RAID 0 and RAID 1
 iTE IT8716 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB  Integrated in the NVIDIA
®
GeForce 6100/nForce 430 chipset
 Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
Internal Connectors  1 x 24-pin ATX main power connector
 1 x 4-pin ATX 12V power connector
 1 x floppy disk drive connector
 1 x IDE connector
 2 x SATA 3Gb/s connectors
 1 x CPU fan header
 1 x system fan header
 1 x front panel header
 1 x front panel audio header
 1 x CD In connector
 1 x S/PDIF Out header
 2 x USB 2.0/1.1 headers
 1 x chassis intrusion header
 1 x power LED header

Gigabyte GA-M61PME-S2 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Processor system buses supported	2000 MHz
S/PDIF out connector	Yes
Number of Parallel ATA connectors	1
Controller interface type	SATA
Controller 2nd interface type	IDE
Headphone outputs	3
USB 2.0 ports quantity	4
BIOS type	AWARD
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Bundled software	Norton Internet Security
Networking features	Gigabit Ethernet
RAID levels	0, 1

Weight and Dimensions

Depth	225 mm
Width	244 mm
