Gigabyte GA-Z77P-D3 User Manual

- 11 - Hardware Installation
Storage Interface Chipset: 
- 2 x SATA 6Gb/s connectors (SATA3 0/1) supporting up to 2 SATA 6Gb/s
devices
- 3 x SATA 3Gb/s connectors (SATA2 2/3/4) supporting up to 3 SATA 3Gb/s
devices
- 1 x mSATA connector
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
* When a RAID set is built across the SATA 6Gb/s and SATA 3Gb/s channels, the
system performance of the RAID set may vary depending on the devices being
connected.
USB Chipset: 
- Up to 4 USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
* In Windows XP, the Intel USB 3.0 ports can support up to USB 2.0 transfer speed.
- Up to 8 USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through
the internal USB header)
Internal
Connectors
1 x 24-pin ATX main power connector 
1 x 4-pin ATX 12V power connector 
2 x SATA 6Gb/s connectors 
3 x SATA 3Gb/s connectors 
1 x mSATA connector 
1 x CPU fan header 
3 x system fan headers 
1 x front panel header 
1 x front panel audio header 
1 x S/PDIF Out header 
1 x USB 3.0/2.0 header 
2 x USB 2.0/1.1 headers 
1 x Clear CMOS jumper 
1 x Trusted Platform Module (TPM) header 
Back Panel
Connectors
1 x PS/2 mouse port 
1 x PS/2 Keyboard port 
1 x serial port 
1 x HDMI port 
2 x USB 3.0/2.0 ports 
4 x USB 2.0/1.1 ports 
1 x RJ-45 port 
3 x audio jacks (Line In/Line Out/Microphone) 
I/O Controller iTE I/O Controller Chip 

Gigabyte GA-Z77P-D3 Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel Z77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16+1x4
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX
LAN controller	-
Wi-Fi standards	Not supported
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	215 mm
Width	305 mm
