GN-BTP01 Bluetooth USB Printer Adapter
5
n Remote wake up Printer
n Highly compatible with versatile printers.
n Support client side Widcom Bluetooth stack software
n High performance radio transceiver
n Supporting HCRP & SPP profile
n Low power standby mode to enable very efficient Power Management
n Weight: 30g+-5g
n Dimensions: 80mm x 43mm x 16mm
n One-year manufacturer warranty
1.4 Feature
1.5 Specification
Standard Fully Bluetooth V1.1 Bluetooth operation
Interface USB male B type
Frequency range 2.4~2.483 GHz
Channel number 79
Modulation FHSS( Frequence hopping spreading spectrum )
Antenna External antenna supporting diversity
Coverage 100 meters
RX Sensitivity @ BER 0.1% Typical. -80 dbm, Min -70 dbm ,max -85 dbm
LED indicators Power on, Link Status
