- 7 - Hardware Installation
DVI Output
2. Hardware Installation
2.1. Board Layout
HDMI Connector
DVI-D Connector
DVI-D
Connector
Digital LCD Monitor
D-Sub Monitor Connector
(15-pin)
D-Sub Monitor
Connector
(15-pin)
D-Sub Output
Analog LCD Monitor Analog CRT Monitor
or
1. GV-R667OC-1GI
HDMI TV
HDMI
Connector
HDMI TV
