- 41 - System Hardware Installation
3-11 Cable Routing
3-11-1 R152-Z30 Cable Routing
HDD Back Plane Board Power Cable HDD Back Plane Board Signal Cable
Front Panel USB 3.0 CableFront Switch Cable/Front LED Cable

Table of Contents

Other manuals for Gigabyte R152-Z30

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Gigabyte R152-Z30 and is the answer not in the manual?

Gigabyte R152-Z30 Specifications

General IconGeneral
Form Factor1U Rackmount
Memory Slots16 x DIMM slots
ProcessorAMD EPYC 7002/7003 series
Maximum Memory4TB
OCP Slot1 x OCP 3.0 slot
Power SupplyDual 800W 80 PLUS Platinum
ManagementIPMI 2.0
Storage Bays10 x 2.5" SATA/SAS (8 x NVMe supported)
