Hardware Installation - 12 -
1-2 Product Specications
CPU 3rd Generation Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon®
Silver Processor
10nm technology, CPU TDP up to 270W
NOTE: If only 1 CPU is installed, some PCIe or memory functions might be
unavailable.
Socket 2 x LGA 4189
Socket P+
Chipset
Intel® C621A Express Chipset
Memory 32 x DIMM slots
DDR4 memory supported only
8-channel memory architecture per processor
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
1.2V modules: 3200/2933/2666 MHz
LAN 2 x 1Gb/s LAN ports (Intel® I350-AM2)
1 x 10/100/1000 management LAN
Expansion Slot Riser Card CRS2033:
1 x PCIe x16 slot (Gen4 x16), Full height half-length
2 x PCIe x8 slots (Gen4 x8), Full height half-length
Riser Card CRS2137:
1 x PCIe x16 slot (Gen4 x16 o x8), Full height half-length
1 x PCIe x8 slots (Gen4 x0 or x8), Full height half-length
1 x PCIe x16 slot (Gen4 x16 or x8), shared with OCP 2.0, Full height half-length
Riser Card CRS2027:
2 x PCIe x8 slots (Gen4 x8), Low prole half-length
1 x OCP 3.0 mezzanine slot with PCIe Gen4 x16 bandwidth from CPU_0
Supported NCSI function
1 x OCP 2.0 mezzanine slot with PCIe Gen3 x8 bandwidth from CPU_1
Supported NCSI function
Video R282-3C0
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
R282-3C1
Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
To Next Page
