2-2 The Main Menu
Hardware
Information
Option Description
Current Settings
Setup
Menus
Conguration
Items
System Time
Quick Access Bar allows you to quickly move to
the General Help, Easy Mode, Smart Fan 5, or
Q-Flash screen.
Advanced Mode Function Keys
<
f
><
g
> Move the selection bar to select a setup menu
<
h
><
i
> Move the selection bar to select an conguration item on a menu
<Enter>/Double Click Execute command or enter a menu
<
+
>/<Page Up> Increase the numeric value or make changes
<
-
>/<Page Down> Decrease the numeric value or make changes
<F1> Show descriptions of the function keys
<F2> Switch to Easy Mode
<F3> Save the current BIOS settings to a prole
<F4> Load the BIOS settings from a prole created before
<F5> Restore the previous BIOS settings for the current submenus
<F6> Display the Smart Fan 5 screen
<F7> Load the Optimized BIOS default settings for the current submenus
<F8> Access the Q-Flash utility
<F10> Save all the changes and exit the BIOS Setup program
<F11> Switch to the Favorites submenu
<F12> Capture the current screen as an image and save it to your USB drive
<Insert> Add or remove a favorite option
<Ctrl>+<S>
Display information on the installed memory
<Esc> Main Menu: Exit the BIOS Setup program
Submenus: Exit current submenu
- 23 -

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Gigabyte X570 I AORUS PRO WIFI and is the answer not in the manual?

Gigabyte X570 I AORUS PRO WIFI Specifications

General IconGeneral
Processor socketSocket AM4
Processor manufacturerAMD
Compatible processor seriesAMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Audio chipRealtek ALC1220-VB
Component forPC
Motherboard chipsetAMD X570
PC health monitoringFAN, Temperature, Voltage
Audio output channels7.1 channels
Motherboard form factormini ITX
Windows operating systems supportedYes
Memory channelsDual-channel
Number of memory slots2
Supported memory typesDDR4-SDRAM
Maximum internal memory64 GB
Supported memory clock speeds2133, 2400, 2667, 2933, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400 MHz
RAID levels0, 1, 10
Supported storage drive interfacesM.2, SATA III
Maximum resolution4096 x 2304 pixels
Number of displays supported3
Parallel processing technology support-
PCI Express x16 slots1
Number of SATA III connectors4
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
DisplayPort version1.2
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version5.0
Ethernet interface typeFast Ethernet, Gigabit Ethernet
BIOS typeUEFI AMI
BIOS memory size128 Mbit
Desktop Management Interface (DMI) version2.7
Bundled softwareNorton® Internet Security (OEM version) cFosSpeed XSplit Gamecaster + Broadcaster (12 months license)
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Width170 mm
