Gigabyte X570 I AORUS PRO WIFI User Manual

Expansion Slots Integrated in the CPU (PCIEX16):
 3rd Generation AMD Ryzen
™
processors:
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
 2nd Generation AMD Ryzen
™
processors:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
 2nd Generation AMD Ryzen
™
with Radeon
™
Vega Graphics processors/AMD
Ryzen
™
with Radeon
™
Vega Graphics processors:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8
Integrated in the Chipset:
 1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)
Storage Interface Integrated in the CPU (M2A_SOCKET):
 3rd Generation AMD Ryzen
™
processors:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 4.0 x4/
x2 SSD support)
 2nd Generation AMD Ryzen
™
processors/2nd Generation AMD Ryzen
™
with
Radeon
™
Vega Graphics processors/AMD Ryzen
™
with Radeon
™
Vega Graphics
processors:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/
x2 SSD support)
Integrated in the Chipset (M2B_SOCKET):
- 1 x M.2 connector on the back of the motherboard (Socket 3, M key, type
2260/2280 SATA and PCIe 4.0
(Note 2)
/3.0 x4/x2 SSD support)
- 4 x SATA 6Gb/s connectors
- Support for RAID 0, RAID 1, and RAID 10
USB  Integrated in the CPU:
- 4 x USB 3.1 Gen 1 ports on the back panel
 Integrated in the Chipset:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
- 1 x USB 3.1 Gen 2 Type-A ports (red) on the back panel
- 2 x USB 3.1 Gen 1 ports available through the internal USB headers
- 2 x USB 2.0/1.1 ports available through the internal USB headers
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 2 x system fan headers
 1 x addressable LED strip header
 1 x RGB LED strip header
 4 x SATA 6Gb/s connectors
 2 x M.2 Socket 3 connectors
 1 x front panel header
 1 x front panel audio header
 1 x speaker header
 1 x USB 3.1 Gen 1 header
 1 x USB 2.0/1.1 header
 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only)
 1 x Clear CMOS jumper
(Note 2) For 3rd Generation AMD Ryzen
™
processors only.
- 8 -

Gigabyte X570 I AORUS PRO WIFI Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Audio chip	Realtek ALC1220-VB
Component for	PC
Motherboard chipset	AMD X570
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Windows operating systems supported	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400 MHz
RAID levels	0, 1, 10
Supported storage drive interfaces	M.2, SATA III
Maximum resolution	4096 x 2304 pixels
Number of displays supported	3
Parallel processing technology support	-
PCI Express x16 slots	1
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
DisplayPort version	1.2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	UEFI AMI
BIOS memory size	128 Mbit
Desktop Management Interface (DMI) version	2.7
Bundled software	Norton® Internet Security (OEM version) cFosSpeed XSplit Gamecaster + Broadcaster (12 months license)
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170 mm
