Gigabyte Z390 UD V2 User Manual

1-7 Internal Connectors
Readthefollowingguidelinesbeforeconnectingexternaldevices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X2/ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3
5) LED_C
6) SATA3 0/1/2/3/4/5
7) M2A
8) F_PANEL
9)
F_AUDIO
10)
SPDIF_O
11) F_USB30
12) F_USB
13) TPM
14) COM
15) THB_C
16) BAT
17) CLR_CMOS
18) CPU/DRAM/VGA/BOOT
2
4 8
1
1
3
7
12
4
11
15
10 59 14
17
6
6
13
18
16
4
- 12 -
