1-2 ProductSpecications
CPU  Support for 9th and 8th Generation Intel
®
Core
™
i9 processors/Intel
®
Core
™
i7
processors/Intel
®
Core
™
i5 processors/Intel
®
Core
™
i3 processors/Intel
®
Pentium
®
processors/Intel
®
Celeron
®
processors in the LGA1151 package
(Go to GIGABYTE's website for the latest CPU support list.)
 L3 cache varies with CPU
Chipset  Intel
®
Z390 Express Chipset
Memory  4xDDR4DIMMsocketssupportingupto128GB(32GBsingleDIMMcapacity)
of system memory
 Dual channel memory architecture
 SupportforDDR42666/2400/2133MHzmemorymodules
 SupportforECCUn-bufferedDIMM1Rx8/2Rx8memorymodules(operatein
non-ECC mode)
 Supportfornon-ECCUn-bufferedDIMM1Rx8/2Rx8/1Rx16memorymodules
 SupportforExtremeMemoryProle(XMP)memorymodules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
 Integrated Graphics Processor-Intel
®
HD Graphics support:
- 1xHDMIport,supportingamaximumresolutionof4096x2160@30Hz
* Support for HDMI 1.4 version and HDCP 2.2.
 Maximum shared memory of 1 GB
Audio  Realtek
®
audio codec
 HighDenitionAudio
 2/4/5.1/7.1-channel
* Tocongure7.1-channelaudio,youneedtoopentheaudiosoftwareandselect
Deviceadvanced settings > Playback Device to change thedefaultsettingrst.
PleasevisitGIGABYTE'swebsitefordetailsonconguringtheaudiosoftware.
 Support for S/PDIF Out
LAN  Realtek
®
GbELANchip(1000/100Mbit)
Expansion Slots  1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
 2 x PCI Express x16 slots, running at x4 (PCIEX4_1/PCIEX4_2)
 3 x PCI Express x1 slots
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
Multi-Graphics
Technology
 Support for AMD Quad-GPU CrossFire
™
and 2-Way AMD CrossFire
™
technologies
Storage
Interface
 Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe x4/x2 SSD support)
- 6 x SATA 6Gb/s connectors
- SupportforRAID0,RAID1,RAID5,andRAID10
* Referto"1-7InternalConnectors,"fortheinstallationnoticesfortheM.2andSATA
connectors.
 Intel
®
Optane
™
MemoryReady
- 6 -

Gigabyte Z390 UD V2 Specifications

General

Brand	Gigabyte
Model	Z390 UD V2
Category	Motherboard
Language	English
