Gigabyte Z790 UD AX - Internal Connectors

- 20 -
2-8 Internal Connectors
1)
ATX_12V_2X4_1/2jkl,
ATX_12V_2X2m/ATX_12V_2X4m
2) ATX
3) CPU_FAN
4) SYS_FAN1/2A/2B
5) SYS_FAN3_PUMP
6) CPU_OPT
7) LED_C1/LED_C2
8) D_LED1/D_LED2
9) SATA3 2/3/4/5/6/7
10) M2A_CPU/M2P_SB/M2Q_SB
11) F_PANEL
12) F_AUDIO
13) SPDIF_O
14) F_U32C
15) F_U32
16) F_USB1/F_USB2
17) COM
18) SPI_TPM
19) THB_C1/THB_C2
20) CLR_CMOS
21) BAT
22) RST
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
11
4
8
7
3
2
7
6 8
1
4
14
10
10
10
9
19
15
12
13
17
18
16 5
22
20
21
jOnly for Z790 UD AX. lOnly for Z790 UD.
kOnly for Z790 UD AC. mOnly for Z790 D DDR4.
