For logging high frequencies please make sure to remember
the settings of the connected HF-Analyser, as they will not
be registered by the NFA. You may use the audio note fea-
ture for that.
This input can also be used for the connection of an option-
ally available magnetostatic and electrostatic sensor.
= Input socket for body voltage hand
probe
Input for the connection of a hand probe for the measure-
ment of body voltage in mV. The connector is a 4 mm bana-
na jack. For displaying and recording, set the “Mode”-switch
to
/
and plug in the grounding cable.
This is the only input which cannot be recognized automati-
cally (being single-pole).
= Socket for the grounding cable
Allows the connection of a grounding cable for an E-field
measurement with reference to ground (in compliance with
TCO). This will be detected automatically by the instrument
and the display will change to E-field with reference to
ground correspondingly.
Socket for the TCO-conformed probe at
the front end of the meter
This is for the TCO-conformed probe available as an option-
al accessory from Gigahertz Solutions.
4.4 Mode = Selection of Meas-
urement Mode
Selects all measurement and display op-
tions of the instrument with the field selec-
tor switch and the “Mode >” button. Con-
figuration errors will be detected and indi-
cated by “Err.” on the display until re-
solved.
When set to
the NFA recognizes
probes connected to it, and shows the cor-
responding values. If there is no external
probe connected to the instrument, it will
show the selected 3D field type. By press-
ing the mode button, you can “toggle” between the primary
Mode
Freq.
Band
Auto
/
