FC 203B FRACTION COLLECTOR | QUICK REFERENCE GUIDE
Key COntrOls
Del
Press to delete the collection window currently shown on
the top line of the display. To collect from start to end,
delete all collection windows. Refer to the user’s guide for
detailed instructions.
Delayed Adv
In manual mode, this soft key functions like ADV, except
tube advance is delayed to account for the time it
takes effluent to pass from the detector to the fraction
collector.
Discard
In peak modes, press to divert the non-peak effluent to
the drain.
Drop
Specifies collection in drop mode. Refer to
Collection Modes on page 2 for more information.
Back
After viewing a HELP message, press this key to return to
the point at which HELP was requested.
List
Press to display a listing of each option and its current
value in the selected collection mode.
Manl
Specifies collection in manual mode. Refer to
Collection Modes on page 2 for more information.
