FC 203B FRACTION COLLECTOR | QUICK REFERENCE GUIDE
Key COntrOls
Key Controls
“Hard” Keys
START
Key used to start collection. This key has the same
function as the Start Soft Key. It is also possible to start
the fraction collector remotely; refer to the user’s guide.
END
A manual override key that ends the collection and
returns the dispense head to the “home” position at the
left and rear of the unit. Typically, the dispense head will
return to “home” after collecting into the last tube in the
rack.
When using the multiple column option, press END after
the last fraction has been collected.
If END is pressed while viewing any display, the ready-
to-run display of the current mode will appear. It is then
possible to begin collecting fractions.
EDIT
Key that calls up the display you use to select or change
collection modes. To access advanced technical and
service options, press EDIT 1, 2, or 3. Refer to the
appendices in the user’s guide for more information
about those options.
