GIRBAU RMS628 Installation Instruction

Technical specifications 7
Cod. 598250
Rev. 09/0918
1. TECHNICAL SPECIFICATIONS
1.1. Tools needed for installation
 Bolting nuts M12 ................................ open end or ring wrench 3/4 in (19 mm)
 Bolting nuts M14 ................................ open end or ring wrench 7/8 in (21 mm)
 Bolting nuts M16 ................................ open end or ring wrench 5/16 in (24 mm)
 Clamps fixing ..................................... tubular wrench 7 mm
 Water inlet coupling ........................... open end wrench 1 3/8 in (34 mm)
 Covers fixing ...................................... Torx T20 screwdriver
 Covers fixing ...................................... Torx T25 screwdriver
 Water inlet hoses ............................... slip-joint pliers or pipe wrench diam. 1 1/2 in (35 mm)
 Electrical connection .......................... Phillips screwdriver 2 mm. (#2)
 External dosing connection ............... slotted-head screwdriver 3 mm.
 Vending circuit connection................. slotted-head screwdriver 3 mm & Philips 1 (#1)
1.2. Accessories in machine
Keep all machine instructions in a safe place.
ACCESSORIES
QUANTITY
NOTES
Bolting nuts and hoses ............................ 4 (5)
Hold-down washer ................................... 4 (6)
Drain hose ............................................... 1
Clamp 50-70 ............................................ 1
Cold water inlet hose ............................... 1 (1)
Hot water inlet hose ................................. 1 (1)
Water inlet coupling ................................. 2 (2)
Water inlet gasket .................................... 2 (2)
Top cover lock key .................................. 1
Coin meter box lock key .......................... 1 (3, 4)
Coin meter tokens ................................. 10 (3, 4)
Fuse 8 A .................................................. 1
Fuse 2.5 A ............................................... 2
Installation handbook .............................. 1
Operation handbook ................................ 1
Parts handbook ....................................... 1 (4)
Documentation ..................................... - - (4)
(1) not available USA / Canada
(2) available USA / Canada only
(3) Coin control models only
(4) depending on target country
(5) for RMS/RMG628 and REM/RMG070
quantity 6
(6) for RMS/RMG628 and REM/RMG070
quantity 6 top washers + 2 bottom
washers
