8.6.1 SPEED OF TRANSMISSION
1. Press the key
to access the parameter
2. Press the key
to choose the data exit mode wanted.
3. Press the key
to confirm.
SPEED OF TRANSMISSIOIN
b1200 1200 baud
b2400 2400 baud
b4800 4800 baud
b9600 9600 baud
b19200 19200 baud
b38400 38400 baud
4. Press the key to choose the speed of transmission needed.
5. Press the key to confirm.
8.6.2 PROTOCOL OF COMMUNICATION
UART SIGNAL OF EIA-RS232 C
Exit serie 1200 / 2400 / 4800 / 9600 / 19200 / 34800 bps
Bits of data 8 bits
Bits of parity No
Bits of stop 1 bit
HEADBOARDS INFORMATION
Headboard 1 (2 BYTES) Headboard 2 (2 BYTES)
OL – overweight
ST – steady NT – Net weight
US – UNSTEADY GS – Gross weight
FORMAT 1 (232 1 ~ 3):
18 BYTES ASCII FOR THE UNITIES kg, g, t, lb
1 2 , 1 2 , 1 2 3 4 5 6 7 8 1 2 CR LF
Headboard 1 Headboard 2 data Unit
21 BYTES ASCII FOR THE UNITIES tl, T, lboz
1 2 , 1 2 , 1 2 3 4 5 6 7 8 9 1 2 3 4 CR LF
Headboard 1 Headboard 2 data Unit
19 BYTES ASCII FOR THE UNIT pcs
1 2 , 1 2 , 1 2 3 4 5 6 7 8 1 2 3 CR LF
Headboard 1 Headboard 2 data Unit
