GISMA 10 Series - Page 15

Handling instructions
for GISMA connectors
HI – 2007 - 001
Document: replaces
MV 2000-020,
MV 2000-030 and
MV 2005 - 011
First issue: 15.07.2008
Rev.-Index: -Z-
From: 29.07.2020
Copyright by:
GISMA GmbH
Page 15 of 44
Picture: boot seal fastening set
Fill the oil reservoir entirely with oil by a syringe. Make sure the oil can’t drain until the hose system
is completely filled with oil.
GISMA will supply boot seal material specimen (Viton) for oil compatibility check on request.
