Maintenance & Adjustment
Formula - 20071
32
Refer to the following chart for fitting locations and lubrication schedule.
Grease Point Location
Initial
Pumps
No. of Grease
Points
Service Interval
Front wheel hubs 2 2 8 hours
Front wheel pivots 2 2 8 hours
Rear height adjust pivots 1 2 40 hours
Deck idler pivots 1 1 40 hours
Hydro idler pivot 1 1 40 hours
Gearbox idler pivot 1 1 40 hours
Deck spindles 2 3 40 hours
Universal joint 1 1 200 hours
