Use
Bracket Slide
Parasol base (optional)
Mast
Crank
Cover
Struts
1. Turn the crank until the desired
inclination is reached
2
Positioning of the canopy inclination
1. Open the xing lever at the base
tube clamp
2. Turn the sunshade to the
requested position
3. Tighten the xing lever again
Turning the parasol
3
360°
1
1. Remove protective cover
2. Detach strap / belt
3. Extend bracket to the opening stop
4. Completely open the parasol
through use of the crack
5. Make sure that the inner parts are
engaging
Opening the parasol
The parasol will be automatically
aligned horizontally. For safe operation,
the inner parts must be completely
engaged.
!
1.3
1.4
1.5
1. Pull out / wrap fabric segments
2. Secure the parasol with a
binding strap / belt
3. Lift the protective cover above the
parasol section
4. Close the protective cover
Bind/protect the parasol
5
Position the rod on the side of the
parasol.
!
5.3
5.2
5.1
To close the sunshade, the canopy
needs to be in a horizontal position.
1. Set sunshade horizontally
2. Turn the hand crank until the
sunshade is closed
3. Push in the unlock button
4. Pull the bracket back
Closing the parasol
4
4.1
4.2
4.4
